Compression Seal Expansion Joint

Name: Compression Seal Expansion Joint
Brand: APS INFRA PROJECTS
Price: 75 INR
Availability: InStock

Price 75 INR/ Kilograms

Get a Price/Quote

MOQ : 5000 Kilograms

Compression Seal Expansion Joint Specification

Max. Temperature
120C

Media
Water, Slurry, Chemical

Flange
Without Flange

Head Code
Flat

Surface Treatment
Painted

Material
EPDM Rubber / Neoprene Rubber

Usage
Bridge

Technique
Compression Moulded

Type
Expansion Joint

Connecting Type
Press-Fit / Embedded

Shape
Rectangular / Strip

Product Type
Compression Seal Expansion Joint

Color
Grey

Working Pressure
Up to 5 bar

Abrasion Resistance
Good

Color
Black / Grey

Length Range
1000 mm - 6000 mm or Custom

Usage
Bridge Decks, Parking Structures, Highways

Installation
Easy to Install; Push Fit System

Weather Resistance
Excellent

Movement Accommodation
30 mm - 70 mm

Chemical Resistance
High

UV Resistance
Yes

Width Range
50 mm - 300 mm

Compression Seal Expansion Joint Trade Information

Minimum Order Quantity
5000 Kilograms

Payment Terms
Cash in Advance (CID)

Supply Ability
300000 Kilograms Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Compression Seal Expansion Joint

From our extensive product range, our clients can avail a qualitative Compression Seal Expansion Joint. The offered expansion joint is demanded to provide a watertight seal between two structural elements, while allowing them to move independently without causing damage to the overall structure. Compression Seal Expansion Joint is easy to install and maintain, and require little maintenance over time. This expansion joint is made from high-quality rubber or neoprene materials that are designed to be flexible and long-lasting. Moreover, this expansion joint provides a watertight seal between two structural elements, while allowing them to move independently without causing damage to the overall structure.

Optimal Movement Accommodation

The compression seal expansion joint is specifically crafted to effectively absorb structural expansion or contraction caused by temperature fluctuations, traffic loads, or seismic activity. With the capacity to accommodate movement between 30 mm and 70 mm, its flexibility ensures the integrity and longevity of infrastructure such as bridges, even under varying environmental pressures.

Durable and Weather-Resistant Design

Manufactured from high-grade EPDM or Neoprene rubber, this expansion joint is resistant to harsh weather, UV rays, and aggressive chemicals. The painted surface treatment provides additional abrasion resistance, making it suitable for challenging environments where longevity and minimal maintenance are critical to operational success.

Simple, Versatile Installation

The push fit system allows for quick and reliable installation, minimizing downtime and labor costs. With its press-fit or embedded connecting options, the joint can be installed efficiently in both new constructions and retrofitting projects. Available in standard and custom sizes, it can be tailored for unique structural requirements across various applications.

FAQ's of Compression Seal Expansion Joint:

Q: How is the compression seal expansion joint installed?

A: This joint utilizes a push-fit system, which enables simple and efficient installation without the need for additional flange connections. The installer presses the joint into place, making it suitable for both press-fit and embedded applications.

Q: What are the primary benefits of using EPDM or Neoprene rubber in this joint?

A: EPDM and Neoprene rubber provide outstanding weather, UV, and chemical resistance. They also deliver excellent flexibility and abrasion resistance, making them ideal materials for expansion joints exposed to harsh environmental and operational conditions.

Q: When should a compression seal expansion joint be used?

A: These joints are ideal when you need to accommodate structural movement from 30 mm to 70 mm, such as in bridge construction, where temperature changes, vibration, and traffic loads can impact stability and durability.

Q: Where can this expansion joint be applied?

A: This product is primarily designed for bridge installations but can also be used in other structures requiring expansion and movement management - particularly where exposure to water, slurry, and chemicals is expected.

Q: What is the process for customizing length and width for specific project needs?

A: You can specify your required length (from 1000 mm to 6000 mm or custom) and width (50 mm to 300 mm) at the time of ordering. The manufacturer will produce the joint to suit your project's unique parameters, ensuring a precise fit and optimal performance.

Q: What types of media can this expansion joint handle?

A: This joint is engineered to handle water, slurry, and various chemicals, remaining effective under working pressures up to 5 bar and temperatures up to 120C, thanks to its robust, chemically resistant materials.
